Good morning folks.

I have a PS Script that I created a few years back, that gathers specific info on a machine, then compiles them all and saves the results as a .html file. I am starting to have servers with more than one IP & Gateway on them, so I am trying to nicely format the results with a “/” between them. Such as “192.168.1.1 / 192.168.1.2” for the IP, “192.168.1.3 / 192.168.1.4” for the DNS, etc. etc. I am having issues with displaying the “/” and returning the correct results, etc.

So my original code for this section is this (please no laughing - I need to redo this code, but this was my 1st attempt at powershell scripting 4 years ago):

$Report+= @"
	</TABLE>
	</DIV>
	</DIV>
	</DIV>
	<DIV class=filler></DIV>
		<DIV class=container>
			<DIV class=heading1>
				<SPAN class=sectionTitle tabIndex=0>NIC Configuration</SPAN>
				<A class=expando href='#'></A>
			</DIV>
			<DIV class=container>
				<DIV class=tableDetail>
					<TABLE>
"@
	Foreach ($objAdapter in $colAdapters)
	{
    foreach ($adapter in $networkAdapters)
    {
        if ($objAdapter.InterfaceIndex -eq $adapter.InterfaceIndex)
        {
            $objAdapter | Add-Member -NotePropertyName NetConnectionId -NotePropertyValue $adapter.NetConnectionId
        }
    }

		if ($objAdapter.IPEnabled -eq "True")
		{
			$NICCount = $NICCount + 1
			If ($NICCount -gt 1)
			{
				$Report+=  "</TABLE>"
				$Report+=  "<DIV class=Solidfiller></DIV>"
				$Report+=  "<TABLE>"
			}
		$Report+=  "<tr>"
		$Report+=  "<th width='25%'><b>Description</b></font></th>"
		$Report+=  "<td width='75%'>$($objAdapter.NetConnectionId)</font></td>"
		$Report+=  "</tr>"
		$Report+=  "<tr>"
		$Report+=  "<th width='25%'><b>MAC Address</b></font></th>"
		$Report+=  "<td width='75%'>$($objAdapter.MACaddress)</font></td>"
		$Report+=  "</tr>"
		If ($objAdapter.IPAddress -ne $Null)
		{
			$Report+=  "<tr>"
			$Report+=  "<th width='25%'><b>IP Address</b></font></th>"
			$Report+=  "<td width='75%'>$(Get-CimInstance -ComputerName $Target -ClassName Win32_NetworkAdapterConfiguration | Where-Object { $_.IPEnabled -eq $true } | Foreach-Object { $_.IPAddress } | Foreach-Object { [IPAddress]$_ } | Where-Object { $_.AddressFamily -eq 'Internetwork' } | Foreach-Object { $_.IPAddressToString })</font></td>"
			$Report+=  "</tr>"
			$Report+=  "<tr>"
			$Report+=  "<th width='25%'><b>Subnet Mask</b></font></th>"
			$Report+=  "<td width='75%'>$($objAdapter.IPSubnet)</td>"
			$Report+=  "</tr>"
			$Report+=  "<tr>"
			$Report+=  "<th width='25%'><b>Default Gateway</b></font></th>"
			$Report+=  "<td width='75%'>$($objAdapter.DefaultIPGateway)</font></td>"
			$Report+=  "</tr>"
		}
		$Report+=  "<tr>"
		$Report+=  "<th width='25%'><b>DNS Servers</b></font></th>"
		$Report+=  "<td width='75%'>"
		If ($objAdapter.DNSServerSearchOrder -ne $Null)
		{
			$Report+=  "$($objAdapter.DNSServerSearchOrder) "
		}
		$NICCount = $NICCount + 1
		}
	}

I have tried messing around with the code, and I know I am on the right track, but just can’t get the output to show correctly. I just started messing around with the DNS section, so it would show something to the affect of “192.168.4.5 / 192.168.4.6”, but no matter what I do, I just can’t get it to show correctly:

$Report+= @
	</TABLE>
	</DIV>
	</DIV>
	</DIV>
	<DIV class=filler></DIV>
		<DIV class=container>
			<DIV class=heading1>
				<SPAN class=sectionTitle tabIndex=0>NIC Configuration</SPAN>
				<A class=expando href='#'></A>
			</DIV>
			<DIV class=container>
				<DIV class=tableDetail>
					<TABLE>
"@
	Foreach ($objAdapter in $colAdapters)
	{
    foreach ($adapter in $networkAdapters)
    {
        if ($objAdapter.InterfaceIndex -eq $adapter.InterfaceIndex)
        {
            $objAdapter | Add-Member -NotePropertyName NetConnectionId -NotePropertyValue $adapter.NetConnectionId
        }
    }

		if ($objAdapter.IPEnabled -eq "True")
		{
			$NICCount = $NICCount + 1
			If ($NICCount -gt 1)
			{
				$Report+=  "</TABLE>"
				$Report+=  "<DIV class=Solidfiller></DIV>"
				$Report+=  "<TABLE>"
			}
		$Report+=  "<tr>"
		$Report+=  "<th width='25%'><b>Description</b></font></th>"
		$Report+=  "<td width='75%'>$($objAdapter.NetConnectionId)</font></td>"
		$Report+=  "</tr>"
		$Report+=  "<tr>"
		$Report+=  "<th width='25%'><b>MAC Address</b></font></th>"
		$Report+=  "<td width='75%'>$($objAdapter.MACaddress)</font></td>"
		$Report+=  "</tr>"
		If ($objAdapter.IPAddress -ne $Null)
		{
			$Report+=  "<tr>"
			$Report+=  "<th width='25%'><b>IP Address</b></font></th>"
			$Report+=  "<td width='75%'>$(Get-CimInstance -ComputerName $Target -ClassName Win32_NetworkAdapterConfiguration | Where-Object { $_.IPEnabled -eq $true } | Foreach-Object { $_.IPAddress } | Foreach-Object { [IPAddress]$_ } | Where-Object { $_.AddressFamily -eq 'Internetwork' } | Foreach-Object { $_.IPAddressToString })</font></td>"
			$Report+=  "</tr>"
			$Report+=  "<tr>"
			$Report+=  "<th width='25%'><b>Subnet Mask</b></font></th>"
			$Report+=  "<td width='75%'>$($objAdapter.IPSubnet)</td>"
			$Report+=  "</tr>"
			$Report+=  "<tr>"
			$Report+=  "<th width='25%'><b>Default Gateway</b></font></th>"
			$Report+=  "<td width='75%'>$($objAdapter.DefaultIPGateway)</font></td>"
			$Report+=  "</tr>"
		}
		$Report+=  "<tr>"
		$Report+=  "<th width='25%'><b>DNS Servers</b></font></th>"
		$Report+=  "<td width='75%'>"
$(Get-CimInstance -ComputerName $Target -ClassName Win32_NetworkAdapterConfiguration | Where-Object { $_.IPEnabled -eq $true } | Foreach-Object { $_.IPAddress } | Foreach-Object { [IPAddress]$_ } | Where-Object { $_.AddressFamily -eq 'Internetwork' } | Foreach-Object { $_.IPAddressToString }) -join " / "
		$Report+=  $($objAdapter.DNSServerSearchOrder) -join " / "
	}
	}

I know I am missing something extremely stupid, or have something in the wrong place, but I just can’t figure it out for the life of me. I was trying for the DNS area (as there’s always two listed), and once I get that one figured out, I will duplicate the process for the others such as IP, Gateway, etc., which don’t always have numerous listings.

All help is appreciated!

2

Instead of trying to manually create the HTML have you tried ConvertTo-Html?

3

Totally agree with NeeMoBeer … what I do is define my Style/CSS in a Here-String to get the final HTML to look the way I want.

$.02

4

No I have not. As I mentioned when I posted, I am going to re-write the script to make it more “modern day”, and not look like it was written like the Novice I am! :slightly_smiling_face:

I just want to get the issue resolved 1st before I go re-writing the structure, etc.

5

I was just reading up on the Here String stuff, and that’s what I am starting to venture towards. Just need to do some testing on it and understand it 100%.

6

Charles,
Welcome to the forum. :wave:t3:

Here you have a quite comprehensible blog post about how to create nice html reports with PowerShell. I’m pretty sure you can pick up one or two techniques to improve your script. :wink:

1 Like
7

Good article to start with Olaf. One other small point of note is that you can embed anything in the Here-String that you want in your page. In my case, I have tons of JavaScript that I use in my HTML report to do items such as generating sub reports, sorting columns, printing tables etc.

$.02

2 Likes
8

I will definitely check that out in the next couple days.

The problem I run in to is I know how to do something with Variables one way, then when I change up doing things (such as “ConvertTo-HTML”), the variables and parameters change, and that is what throws me off to all hell. :frowning:

9

Much appreciated! I was reading on that earlier, and will spend some more time over the weekend when I get back from flying. That’ll give me something to do after being in the cockpit for three hours on an AZ May day! :joy:
